SJY LiFePO4 24V 100AH Description:

The following is the description of SJY LiFePO4 24V 100AH from datasheet. You can also check out data sheet.

Product Parameters

Battery Type: Lifepo4 battery pack
Voltage: 12.8V/25.6V/51.2V
Battery Capacity:100Ah/200Ah
Weight: 11kg/21kg/42kg
Span Life: 4000 cycles or more
Operating Temperature: -20~60°C

Scope:

Scope is very needed in SJY LiFePO4 24V 100AH This product is designed and manufactured by Shenzhen Saijiaoyang Energy Technology Co., LTD. LFP battery pack (including BMS). It consists of 8S1P units in series. Battery assembly intelligent sorting, accurate and reliable. BMS uses a professional protection board test system, which is fully tested before going onlinetoensurethat the battery pack is fully and effectively protected by BMS during use. This product has the characteristics of high energy density, long life, safety and reliability, light weight, wide temperature range, etc.

BMS Basic protection function BMS 基本功能介绍

Overcharge protection: When the battery is charged, the voltage continues to rise. Underproduction board detects that the voltage of any cell is higher than that of the battery Charge protection value, the protection board starts timing immediately, when the time reaches the overcharge protection delay, the protection board turns off the charging MOS.Tube, charge cut-off, can not charge at this time.

Overcharge protection recovery is helpful in SJY LiFePO4 24V 100AH After the overvoltage protection occurs on theprotectionboard,the battery voltage drops when the battery is standing or discharging When the protection board detects that the voltage of each section is lower than the overcharge protectionrecoveryvoltage,the protection board outputs the signal and starts the charging MOS tube.It canbechargedatthis point。
Over discharge protection: When the battery is in the discharge state, the voltagecontinuestodecrease, and the protection board detects that the voltage of any cell is lower than overdischarge protection
Protection value, the protection board starts timing immediately, when the timereachestheover-discharge protection delay, the output signal of the protection board turns off the discharge MOS Tube, discharge cutoff, load lock circuit work, can not discharge at this time.

Over discharge protection recovery: After the protection board is over-dischargeprotection,thebattery voltage continues to rise when the battery is standing or charging. When protection board detects that the voltage of each section is higher than the recovery voltage the overdischarge protection, the load is disconnected or charged again at this time, underproduction board outputs Out of the signal, open the discharge MOS tube, at this time can discharge
